UNV 5MP HD Wide Angle 180° Field of View NDAA Compliant Weatherproof IR Fixed Turret IP Security Camera with Deep Learning AI (IPC3605SB-ADF16KM-I0)
$599.00
- 180° Wide-Angle Coverage:
- Equipped with an ultra-wide 1.68mm lens providing seamless 180° panoramic view — ideal for full-room or wall-to-wall coverage.
- Reduces blind spots in indoor and outdoor scenes.
- AI Video Analytics:
- Deep Learning AI accurately identifies humans and vehicles, significantly reducing false alarms.
- Supports line crossing, intrusion zones, and area-based detection.
- Smart IR & Night Vision:
- 10-meter IR range with Smart IR ensures balanced exposure even at night.
- Delivers full-scene visibility in complete darkness.
- Audio & Integration:
- Built-in microphone for live audio and recording.
- ONVIF compliant and works with most NVRs, mobile apps, and software clients.
- Durability & Deployment:
- IP67 weatherproof and IK10 vandal-resistant for use in exposed public or industrial areas.
- Ideal for corridors, wide entrances, lobbies, parking structures, and schools.
The UNV IPC3605SB-ADF16KM-I0 is a 5MP ultra-wide turret IP security camera with a 180° panoramic view, built-in mic, and deep learning AI. Featuring smart detection, IR night vision, PoE support, and IK10/IP67 protection, it’s a powerful NDAA-compliant solution for full-scene indoor and outdoor surveillance.
Specifications
| Feature | Detail |
|---|---|
| Camera Type | Fixed Turret Wide-Angle IP Camera with AI |
| Image Sensor | 1/2.7″ Progressive Scan CMOS |
| Effective Resolution | 5 Megapixels (2880 × 1620) |
| Lens Type | 1.68mm Fixed Ultra-Wide Lens |
| Field of View | Horizontal: 180°, Vertical: 96°, Diagonal: 180° |
| Minimum Illumination | 0.005 Lux (Color), 0 Lux (IR On) |
| Infrared Night Vision | Up to 10 Meters |
| WDR (Wide Dynamic Range) | 120dB True WDR |
| Image Enhancements | 3D DNR, BLC, HLC, Defog, ROI |
| Video Compression | Ultra 265 / H.265 / H.264 / MJPEG |
| Max Frame Rate | 30fps @ 5MP |
| AI Functions | Human Body Detection, Vehicle Detection, Line Crossing, Intrusion |
| Smart Features | Motion Detection, Face Detection, Privacy Mask |
| Audio Support | Built-in Microphone |
| Ingress Protection | IP67 Weatherproof |
| Vandal Resistance | IK10 Rated Dome |
| Power Input | 12V DC ±25%, PoE (802.3af) |
| Power Consumption | Max 6.5W |
| Operating Temperature | -30°C to +60°C |
| Mounting Options | Ceiling, Wall, or Pendant Mount |
| Dimensions | Approx. 110 × 90 mm |
| Weight | Approx. 450g |
| Compliance | NDAA, CE, FCC, RoHS |
